1
Disconnect the battery
Disconnect the negative battery terminal first. The starter has a direct power cable that is always hot — never skip this step.
← Back to Kia Sorento Guides
2016–2020 Kia Sorento
2016-2020 Kia Sorento - Starter
🔧🔧🔧 Advanced
2 hours
$120 DIY
Save $230 by doing it yourself! Shop cost: $350
Quick Video Tutorial
Parts You Need
Click links to purchase (we earn from qualifying purchases)
Total Cost
$110.00
| Part Name | Part Number | Price | Buy |
|---|---|---|---|
| Starter motor | — | $110.00 |
💡 Pro tip: Order all parts at once to save on shipping
Step-by-Step Instructions
Follow these steps carefully
2
Locate the starter
Find the starter where the engine meets the transmission bellhousing. Access may require going under the vehicle — use jack stands if so.
3
Remove the wires
Label and remove the main power cable and the solenoid trigger wire. Note which goes where so you reconnect correctly.
4
Remove the mounting bolts
Remove the two or three mounting bolts holding the starter. Support it as you remove the last bolt — it is heavy and can drop.
5
Install the new starter
Position the new starter, install and torque the mounting bolts to spec, reconnect the wires, and reconnect the battery.
6
Test the repair
Start the engine and verify the starter engages cleanly and cranks at normal speed. If it still will not crank, check the battery, cables, and ignition switch.
All Done!
Test your repair before closing everything up. If something doesn't work right, double-check your steps.
⚠️ Common Mistakes to Avoid
- • Not disconnecting the battery
- • Mixing up the wire connections
- • Dropping the starter during removal
- • Not supporting it while unbolting
